| Poles | 1,2,3,4 |
| Rated breaking capacity (A) | 6000,10000 |
| Rated Voltage Ue (V) | 230/400 |
| Electrical Life (t) | 8000 |
| Terminal connection type | Cable / Pin-type busbar |
| Connection | From top and bottom |
| Rated Current In (A) | 1, 2, 4, 6, 10, 16, 20, 25, 32, 40, 50, 63, 80 |
| Rated frequency (Hz) | 50/60 |
| Insulation Voltage Ui (V) | 500 |
| Mechanical life | 20000 |
| Product Keywords | mcb 1 pole,4p 20a mcb breaker,miniature circuit breaker 6ka |
General
1.Overload protection
2.Short circuit protection
3.Controlling
4.Used in residential building, non-residential building, energy source industry and infrastructure.
5.According to the type of instantaneous release classified as follows : type B(3-5)ln, type C(5-10)ln, type D(10-20)ln
CNC OR OEM 1P 180UNITS/CTN 2P 90UNITS/CTN 3P 60UNITS/CTN 4P 45UNITS/CTN 42*26.5*23.4 cm 18kg/ctn
7-18 days after payment ----delivery date should be decided according to production season and order quantity.
The CNC Electric Group Co,.Ltd ,specialized in manufacturing industrial electrical appliance.
CNC holds assets with more than 5 billion RMB,and the plant area amounts to 0.25 million square meters,with over 10,000 emplyees.
CNC Electric owns 15 exclusive distributors .sell over 100 countries CNC Deliver Power For Better Life！
